TV Bracket Wall Mount Slimline Tilting LCD LED 32 39 40 43 49 50 55 60 70 Inch AU
▪ Vertical Tilt: 0 degrees-15 degrees
▪ Distance from wall: approx 37mm
▪ Maximum weight capacity: 50kg
▪ Maximum mounting hole spacing (horizontal): 600mm
▪ Maximum mounting hole spacing (vertical): 400mm
Suits VESA standards：200x200mm, 400x400mm, 600x400mm
▪ Angle Free Tilt Function: By self-locking mechanical construction, it provides effortless adjustment of viewing angle without tightening the knob.
▪ Magnetic Bubble Level: Perfect positioning is guaranteed by removable magnetic bubble level.
▪ Universal Hole Pattern Random hole pattern and side-to-side adjustment allow the mount to fit most of the flat-panel TVs, Support 200x200mm; 400x400m;600x400mm
▪ Safety Lock Built-in Safety screw lock keeps your flat panel TV safe and stable.
▪ Best quality cold-roll steel material provides the best quality.
Mount your Big Screen Plasma or LCD on the wall.
This high-quality bracket is perfect for mounting your new LCD or Plasma to the wall. It's a fixed type bracket, but it does come with a fitting to give it a 15-degree tilt forward if required to suit your viewing position.
This bracket gives you the option to tilt your TV forwards to approximately 15 degrees.
Suits Australian Studs
This bracket is suitable for mounting on Australian standard stud spacings of 200mm,400mm & 600mm. It can also be mounted on brick/concrete walls.
This bracket includes a variety of screws/bolts which are suitable for most installations. Unfortunately, due to the enormous range of TV brands and models available, we're unable to guarantee that the included fixings will suit every installation. Please check the manufacturer's specifications for your screen prior to installing.
Will it fit my screen?
This bracket will fit your TV screen (and not be visible from front on) if your TV is:
- At least 650mm wide.
- At least 410mm tall.
The four threaded mounting holes on the back of your TV need to be:
- No more than 600mm apart side to side.
- No more than 400mm apart top to bottom.
Maximum TV weight capacity is 50kg.
1x Bracket With Necessary Accessories
